How to check the symbol on the charging label (For Europe) (if equipped)
|
Vehicle charging INLET |
Charging connector OUTLET |
|---|---|
 |
  <Symbol location and application example> |
 |
Precautions for charging AC and Trickle charger (Portable charging cable) (AC charging)
-
After opening the charging door, check the charging symbol at the bottom of the warning label.
-
Check the charging connector symbol of the AC and Trickle charger cable.
-
After checking the alphabet letter of the charging symbol, proceed the charging step.
* Refer to More Details.
-
Risk of failure, fire, injury, etc. expected when using the charging connector with unmatched symbol.
Precautions for DC charging (DC charging)
-
After opening the charging door, check the charging symbol at the bottom of the warning label.
-
Check the charging connector symbol at the high speed charging station.
-
After checking the alphabet letter of the charging symbol, proceed the charging step.
* Refer to More Details.
-
Risk of failure, fire, injury, etc. expected when using the charging connector with unmatched symbol.
Electric charging label (For Europe)
The electric charging label is attached on the charging door.
-
Warning for high voltage
-
Symbol for charging door
-
For further details, refer to More Details.
-
Charging voltage and current
(
): AC Single phase
(
): AC 3 phase
5~7: Symbols for charging type. For further details, refer to More Details.
Electric charging label symbol table (For Europe)
|
Supply Type |
Configuration |
Type of Accessory |
Voltage range |
Identifier |
|---|---|---|---|---|
|
AC |
7P |
Vehicle connector and vehicle inlet |
≤480V RMS |
 |
|
Supply Type |
Configuration |
Type of Accessory |
Voltage range |
Identifier |
|---|---|---|---|---|
|
DC |
7P COMBO |
Vehicle connector and vehicle inlet |
50V to 500V |
 |
|
200V to 920V |
 |
