Air conditioning refrigerant label

Example

* The actual air conditioning refrigerant label in the vehicle may differ from the illustration.

Each symbol and specification on the air conditioning refrigerant label is represented below:

  1. Classification of refrigerant

  2. Amount of refrigerant

  3. Classification of Compressor lubricant

  4. Caution

  5. Service manual

You can find out which air conditioning refrigerant is applied your vehicle at the label inside of the engine compartment.

Refer to More Details for more detail on the location of air conditioning refrigerant label.

Caution

AC Repair

It is important that the correct type and amount of oil and refrigerant is used, otherwise, damage to the vehicle may occur. To prevent damage, the air conditioning system in your vehicle should only be serviced by trained and certified Kia technicians.
