2027 Sportage Plug-in Hybrid
2 trims Available
Build Yours
Build Yours

2027 Sportage Plug-in Hybrid

2 trims available.
Edit Trims

Top Features

  • 1.6L Turbo Plug-in Hybrid w/ 268 hp
  • Panoramic Sunroof, Smart Power Liftgate
  • SynTex Seat Trim, Power Driver's Seat
  • Wireless Apple CarPlay® & Android Auto™*
  • Blind-Spot & 360° Surround View Monitor*
  • Driver's Memory Seat, Ventilated Front Seats
  • Harman Kardon® Audio, Navigation*
  • Head-up Display, Heated Rear Outboard Seats*

Technical Specifications

Height: w/ Roof Rails
66.9 in.
66.9 in.
Width
73.4 in.
73.4 in.
Length
184.4 in.
184.4 in.
Wheelbase
108.5 in.
108.5 in.
Track: Front/Rear
63.6 / 63.9 in.
63.6 / 63.9 in.
Ground Clearance
8.3 in.
8.3 in.
Approach Angle
18.9 °
18.9 °
Departure Angle
26.9 °
26.9 °
Breakover Angle
17.7 °
17.7 °
Headroom: Front / Rear w/ Panoramic Sunroof
39.6 / 39.1 in.
39.6 / 39.1 in.
Shoulder Room: Front / Rear
57.5 / 55.6 in.
57.5 / 55.6 in.
Hip Room: Front / Rear
54.8 / 53.4 in.
54.8 / 53.4 in.
Legroom: Front / Rear
41.4 / 39.5 in.
41.4 / 39.5 in.
Cargo volume (SAE): Behind rear seat / Rear seat folded down (Dual-level cargo floor, lowest position)
34.5 / 65.5 cu. ft.
34.5 / 65.5 cu. ft.
Curb Weight: All-Wheel Drive (AWD) minimum
4,226 lb.
4,226 lb.
Gross Weight: All-Wheel Drive (AWD)
5,379 lb.
5,379 lb.
Engine Type
1.6 liter Turbocharged 4-Cylinder and Full Parallel Hybrid System
1.6 liter Turbocharged 4-Cylinder and Full Parallel Hybrid System
Displacement
1,598 cc
1,598 cc
Valve Train
Double Overhead Camshafts (DOHC), 4 Valves per cylinder
Double Overhead Camshafts (DOHC), 4 Valves per cylinder
Engine Valve Gear
Dual Continuously Variable Valve Timing (CVVT)
Dual Continuously Variable Valve Timing (CVVT)
Compression Ratio
10.5:1
10.5:1
Fuel Delivery System
Gasoline Direct Injection (GDI)
Gasoline Direct Injection (GDI)
Combined Horsepower
268 hp
268 hp
Combined Torque
271 lb.-ft.
271 lb.-ft.
Engine Horsepower
177 hp @ 5,500 rpm
177 hp @ 5,500 rpm
Engine Torque
195 lb.-ft. @ 1,500-4,500 rpm
195 lb.-ft. @ 1,500-4,500 rpm
Electric Motor Type
AC Synchronous Permanent Magnet Motor
AC Synchronous Permanent Magnet Motor
Electric Motor Horsepower
97 hp @ 2,300-3,600 rpm
97 hp @ 2,300-3,600 rpm
Electric Motor Torque
224 lb.-ft. @ 0-2,100 rpm
224 lb.-ft. @ 0-2,100 rpm
Hybrid Battery Type
Lithium-Ion Polymer
Lithium-Ion Polymer
Hybrid Battery Voltage
360 V
360 V
Hybrid Battery Capacity
38.3 Ah
38.3 Ah
Hybrid Battery Energy
13.8 kWh
13.8 kWh
Hybrid Battery Output
88 kW
88 kW
EVSE 240V Charging Time
≈ 2 Hours
≈ 2 Hours
Dual Level 120V / 240V Portable Charging Cable
Standard
Standard
6-Speed Auto Transmission
Standard
Standard
Regenerative Braking w/ Steering Wheel-Mounted Paddles
Standard
Standard
Drive Modes
Standard
Standard
Terrain Modes
Standard
Standard
Rotary Shifter Dial
Standard
Standard
All-Wheel Drive (AWD)*
Standard
Standard
Fuel Requirement
Regular Unleaded, 87 Octane or higher
Regular Unleaded, 87 Octane or higher
Fuel Tank Capacity
11.1 gal.
11.1 gal.
Layout
Front Engine, All-Wheel Drive (AWD)
Front Engine, All-Wheel Drive (AWD)
Steering Type
Column-Mounted, Motor Driven Power Steering (C-MDPS)
Column-Mounted, Motor Driven Power Steering (C-MDPS)
Front Suspension Type
MacPherson Struts, Gas Shock Absorbers
MacPherson Struts, Gas Shock Absorbers
Rear Suspension Type
Independent, Multi-link, Gas Shock Absorbers
Independent, Multi-link, Gas Shock Absorbers
Vehicle Turning Circle Diameter: (Curb-to-Curb)
38.6 ft.
38.6 ft.
Towing Capacity (w/ Trailer Brakes/ w/o Trailer Brakes)*
2,000/1,653 lb.
2,000/1,653 lb.
Electronic Parking Brake (EPB) w/ Auto-Hold
Standard
Standard
Braking System
4-Wheel Disc w/ Antilock Brake System (ABS)
4-Wheel Disc w/ Antilock Brake System (ABS)
Front Ventilated Brake Disc Diameter
12.8 in.
12.8 in.
Rear Solid Brake Disc Diameter
11.8 in.
11.8 in.
