2027 Carnival MPV
5 trims Available
Build Yours
Build Yours

2027 Carnival MPV

5 trims available.
Edit Trims

Top Features

  • 7-Passenger Seating, Power Sliding Rear Doors
  • 12.3-in. Touchscreen Display w/ Navigation*
  • 18 Driver & Safety Assistance Features*
  • Wireless Apple CarPlay® & Android Auto™*
  • 8-Passenger Seating, 2nd-row Slide-Flex Seating
  • 8-Way Power Driver's Seat
  • Heated Front Seats*
  • SynTex Seat Trim
  • 19-in. Wheels, Smart Power Liftgate
  • Power Front Seats & Driver's Memory Seat
  • Passenger View Camera & Rear Sunshades
  • Roof Rails, Wireless Phone Charger*
  • Dual Sunroofs, 19-in. Black Wheels
  • Blind-Spot & 360° Surround View Monitor*
  • Enhanced Auto Emergency Braking Technology*
  • Ventilated Front Seats, Dual 12.3-in. Displays*
  • Dark Edition Styling w/ Leather Seat Trim
  • Bose Premium Audio & Heated Steering Wheel*
  • Head-up Display & Digital Rearview Mirror*
  • LED Projector Headlights & LED Taillights

Technical Specifications

Height: w/o Roof Rails
68.5 in.
68.5 in.
Not Available
Not Available
Not Available
Height: w/ Roof Rails
Not Available
Not Available
69.9 in.
69.9 in.
69.9 in.
Width: w/o Side Mirrors
78.5 in.
78.5 in.
78.5 in.
78.5 in.
78.5 in.
Width: w/ Side Mirrors
89.2 in.
89.2 in.
89.2 in.
89.2 in.
89.2 in.
Length
203.0 in.
203.0 in.
203.0 in.
203.0 in.
203.0 in.
Wheelbase
121.7 in.
121.7 in.
121.7 in.
121.7 in.
121.7 in.
Track: Front/Rear - 17-inch Wheels
68.9/68.9 in.
68.9/68.9 in.
Not Available
Not Available
Not Available
Track: Front/Rear - 19-inch Wheels
Not Available
Not Available
68.5/68.5 in.
68.5/68.5 in.
68.5/68.5 in.
Ground Clearance
6.8 in.
6.8 in.
6.8 in.
6.8 in.
6.8 in.
Approach Angle
15.4°
15.4°
15.4°
15.4°
15.4°
Departure Angle
20.0°
20.0°
20.0°
20.0°
20.0°
Headroom: w/o Dual Sunroof 1st / 2nd-row / 3rd-row
40.9/39.5/38.6 in.
40.9/39.5/38.6 in.
40.9/39.5/38.6 in.
Not Available
Not Available
Headroom: Dual Sunroof 1st / 2nd-row / 3rd-row
Not Available
Not Available
Not Available
39.7/37.6/36.5 in.
39.7/37.6/36.5 in.
Shoulder Room: 1st / 2nd-row / 3rd-row
64.2/63.2/59.5 in.
64.2/63.2/59.5 in.
64.2/63.2/59.5 in.
64.2/63.2/59.5 in.
64.2/63.2/59.5 in.
Hip Room: 1st / 2nd-row / 3rd-row
59.8/66.4/50.4 in.
59.8/66.4/50.4 in.
59.8/66.4/50.4 in.
59.8/66.4/50.4 in.
59.8/66.4/50.4 in.
Legroom: 1st / 2nd-row / 3rd-row
41.1/40.5/35.6 in.
41.1/40.5/35.6 in.
41.1/40.5/35.6 in.
41.1/40.5/35.6 in.
41.1/40.5/35.6 in.
Cargo Volume (SAE): Minimum/Maximum
40.2/145.1 cu. ft.
40.2/145.1 cu. ft.
40.2/145.1 cu. ft.
40.2/145.1 cu. ft.
40.2/145.1 cu. ft.
Curb Weight: Front-Wheel Drive (FWD) 7-Passenger minimum/maximum
4,555 lb. / 4,555 lb.
Not Available
4,678 lb. / 4,678 lb.
4,762 lb. / 4,762 lb.
4,771 lb. / 4,771 lb.
Curb Weight: Front-Wheel Drive (FWD) 8-Passenger minimum/maximum
Not Available
4,630 lb. / 4,630 lb.
4,725 lb. / 4,725 lb.
4,810 lb. / 4,824 lb.
4,720 lb. / 4,733 lb.
Gross Weight
6,283 lb.
6,283 lb.
6,283 lb.
6,283 lb.
6,283 lb.
Engine Type
3.5 Liter V6
3.5 Liter V6
3.5 Liter V6
3.5 Liter V6
3.5 Liter V6
Displacement
3,470 cc
3,470 cc
3,470 cc
3,470 cc
3,470 cc
Valve Train
Double Overhead Camshafts (DOHC), 4 Valves per cylinder
Double Overhead Camshafts (DOHC), 4 Valves per cylinder
Double Overhead Camshafts (DOHC), 4 Valves per cylinder
Double Overhead Camshafts (DOHC), 4 Valves per cylinder
Double Overhead Camshafts (DOHC), 4 Valves per cylinder
Compression Ratio
12.3:1
12.3:1
12.3:1
12.3:1
12.3:1
Fuel Delivery System
Gasoline Direct Injection (GDI) and Multi-Port Injection (MPI)
Gasoline Direct Injection (GDI) and Multi-Port Injection (MPI)
Gasoline Direct Injection (GDI) and Multi-Port Injection (MPI)
Gasoline Direct Injection (GDI) and Multi-Port Injection (MPI)
Gasoline Direct Injection (GDI) and Multi-Port Injection (MPI)
Horsepower
287 hp @ 6,400 rpm
287 hp @ 6,400 rpm
287 hp @ 6,400 rpm
287 hp @ 6,400 rpm
287 hp @ 6,400 rpm
Torque
260 lb.-ft. @ 5,000 rpm
260 lb.-ft. @ 5,000 rpm
260 lb.-ft. @ 5,000 rpm
260 lb.-ft. @ 5,000 rpm
260 lb.-ft. @ 5,000 rpm
8-Speed Auto Transmission
Standard
Standard
Standard
Standard
Standard
Eco Drive Mode
Standard
Standard
Standard
Standard
Standard
Fuel Requirement
Regular Unleaded, 87 Octane or higher
Regular Unleaded, 87 Octane or higher
Regular Unleaded, 87 Octane or higher
Regular Unleaded, 87 Octane or higher
Regular Unleaded, 87 Octane or higher
Fuel Tank Capacity
19.0 gal.
19.0 gal.
19.0 gal.
19.0 gal.
19.0 gal.
Layout
Front Engine, Front-Wheel Drive (FWD)
Front Engine, Front-Wheel Drive (FWD)
Front Engine, Front-Wheel Drive (FWD)
Front Engine, Front-Wheel Drive (FWD)
Front Engine, Front-Wheel Drive (FWD)
Body Construction
Steel Unibody, Iso-Structure
Steel Unibody, Iso-Structure
Steel Unibody, Iso-Structure
Steel Unibody, Iso-Structure
Steel Unibody, Iso-Structure
Steering Type
Electric, Column-Mounted Motor Driven Power Steering (C-MDPS)
Electric, Column-Mounted Motor Driven Power Steering (C-MDPS)
Electric, Column-Mounted Motor Driven Power Steering (C-MDPS)
Electric, Column-Mounted Motor Driven Power Steering (C-MDPS)
Electric, Column-Mounted Motor Driven Power Steering (C-MDPS)
Front Suspension Type
Independent, MacPherson Struts, Coil Springs
Independent, MacPherson Struts, Coil Springs
Independent, MacPherson Struts, Coil Springs
Independent, MacPherson Struts, Coil Springs
Independent, MacPherson Struts, Coil Springs
Rear Suspension Type
Independent, Multi-link
Independent, Multi-link
Independent, Multi-link
Independent, Multi-link
Independent, Multi-link
Towing Capacity (w/ Brake)*
3,500 lb.
3,500 lb.
3,500 lb.
3,500 lb.
3,500 lb.
Roof Rack Load Capacity
165 lb.
165 lb.
165 lb.
165 lb.
165 lb.
Electronic Parking Brake (EPB)
Standard
Standard
Standard
Standard
Standard
Braking System
4-Wheel Disc w/ Antilock Brake System (ABS)
4-Wheel Disc w/ Antilock Brake System (ABS)
4-Wheel Disc w/ Antilock Brake System (ABS)
4-Wheel Disc w/ Antilock Brake System (ABS)
4-Wheel Disc w/ Antilock Brake System (ABS)
Front Ventilated Brake Disc Diameter
12.8 in.
12.8 in.
12.8 in.
12.8 in.
12.8 in.
Rear Solid Brake Disc Diameter
12.8 in.
12.8 in.
12.8 in.
12.8 in.
12.8 in.
